Metal Spinning Lathe Machine Bucket / Horn / Cone / Parabolic Product Making Machine

Brand Name : jinqiu

Model Number : SG500

Certification : CE and CQC

Place of Origin : WUXI

MOQ : 1

Price : USD or RMB

Delivery Time : 60 DAYS

Packaging Details : steel pallet and wood case

Princple : Spin and turn work piece to form special shape

Process Material thickness : 2.5 mm

Contact Now

Bucket/horn/cone/parabolic product making machine- CNC spinning and turning machine

Application:

SG500 CNC Spinning and Turning Machine(Single Roller) is especially developed to make lights, art wares,kitchen hardwares and auto fittings. It got many patents issued by the State Intellectual Property Office. This device is practical, professional and strong. the lathe has high production efficiency and can complete horn, bucket, cone type, parabolic products. It can also make threading, trimming, flanging and rolling at the same machine tool. it can spin many materials such as carbon steel, stainless steel, aluminum and copper etc. It has solved the traditional problems such as lack of skilled workers. With advanced digital control, it is easy to operate. The machine can improve the production efficiency, machining accuracy and saving the cost of human resources. It is the ideal processing machine for light, automobile, mechanic and other manufacturing industries.

Main Features & Standard Configurations:

* Feeding axles and spindle are control by servo motor

* Hydraulic tailstock.

* Integrated automatic lubrication system makes the maintenance more reliable.

* Choose Siemens 808D CNC system with USB port.

* Meehanite cast iron after aging treatment, with high quality and less deformation.

* Adopt independent spindle unit to ensure good movement precision, stiffness and stability.

* High Precision ball screws to make sure dynamic performance well and positioning accurately.

* Configuration cooling pump.

* Mobile manual pulse generator makes easy to operate.

* Semi-enclosed shield.

Items Technical Parameters
Model SG500
Amount of Rollers 1+
Max. Diameter of material Φ500 mm
Max. Spinning Diameter <Φ500 mm
Max. Length of Work Piece 300 mm
Thickness of material 0.5-2.5 mm (Aluminum,Copper) 0.5-1.2 mm ( Carbon Steel) 0.5-1.0 mm (Stainless Steel)
X-axis Strokes 300 mm
Z-axis Strokes 320 mm
X-axis Force 30 kN
Z-axis Force 30 kN
Tailstock Force 20 kN
Guide Rail kinds Linear Guide Rail
Bed width 320 mm
Rapid Traverse X/Z-axis 12/16 m/min
Servo Torque X/Z-axis 7.5/10 N.m
Pulse Equivalent X/Z-axis 0.001 mm
Positioning Precision 0.010 mm
Repetitive Positioning Accuracy 0.006 mm
Spindle Nose C6
Spindle Taper MT6
Spindle Bore Φ52 mm
Spindle Speed 2500 rpm
Taper of Tailstock Quill MT5
Tailstock Stroke 250 mm
Stroke of Tailstock Quill 200 mm
Diameter of Tailstock Quill Φ82 mm
Tools / Shank Size amount 6/25x25 mm²
Spindle Motor Power 7.5 kw
Hydraulic Power 1.5 kw
Machining Accuracy It 6
Surface Roughness Ra 1.25
Service Voltage 380V AC
Power Capacity 12 KVA
Overall Dimensions 2.5x1.3x1.6 m³
Net Weight 2500 kg
